| Rated traction force | 12000 lbs (5443 kg) | |
| Displacement motor | 50 ml/r | |
| Oil flow | 5~50L/min | |
| Pressure | 11Mpa | |
| Gear reduction ratio | High speed: 13.6:1;Low speed: 42.2:1 | |
| Cable (Dia.× L) | Ø13/32"×83.7′ (Ø10.2mm×25.5m) | |
| Drum Size (Dia.× L) | Ø2.6"×8. 8"(Ø66mm×223mm) | |
| Mounting bolt pattern | 10"×4.5" (254mm×114.3mm) 4-M12 | |
RUNVA 2S HWD 5500 (kg)
€895.40 €740.00
Optional:
Hydraulic valve set 12 V / Hydraulic set 12 V
Hydraulic valve set24V / Hydraulic set 24V
| item | HWD12000 |
| Overall dimensions. | 23.66″×6.89″×6.9″ |
| (L×W×H) | 601mm×175mm×176mm |
| Net weight (Ibs/kg) | 45.9 kg |
SKU
3.B.3
EAN Number:
7439656989989
Certification Mark
Warum winch-shop.eu?
- All items in stock – shipped directly from our own warehouse
- Directly from the manufacturer
- Fast delivery (1-3 days)
- Own service workshop
Optional:
Hydraulic valve set 12 V / Hydraulic set 12 V
Hydraulic valve set24V / Hydraulic set 24V
| Rated traction force | 12000 lbs (5443 kg) | |
| Displacement motor | 50 ml/r | |
| Oil flow | 5~50L/min | |
| Pressure | 11Mpa | |
| Gear reduction ratio | High speed: 13.6:1;Low speed: 42.2:1 | |
| Cable (Dia.× L) | Ø13/32"×83.7′ (Ø10.2mm×25.5m) | |
| Drum Size (Dia.× L) | Ø2.6"×8. 8"(Ø66mm×223mm) | |
| Mounting bolt pattern | 10"×4.5" (254mm×114.3mm) 4-M12 | |
| Line pull lbs.(kg) | Line speed ft/min(m/min) | Line pull force and rope capacity in layers Line pull force | ||||||
| Low speed | High speed | Pressure Mpa (Psi) | Flow rate G/min (L/min) | Low speed | High speed | Low rope | Rated tensile force Lbs.(kg) | Total rope on drum ft (m) |
| 0 | 0 | 2.0 (290.1) | 1.3(5) | 1.5(0.5) | 5.2(1.6) | 1 | 12000(5443) | 15.7(4.8) |
| 3000(1814) | 2000(907) | 4.1(596,6) | 2.6(10) | 3,3(1.0) | 10.8(3.3) | 2 | 9563(4338) | 36,4(11.1) |
| 6000(2722) | 3000(1361) | 6.3(916.7) | 5.3(20) | 6.6(2.0) | 21.6(6.6) | 3 | 7949(3606) | 60.0(18.3) |
| 9000(4082) | 4000(1814) | 8.5(1236.8) | 9.2(35) | 12.5(3.8) | 38.3(11.7) | 4 | 6801(3085) | 83.7 (25.5) |
| 12000(5443) | 5000(2268) | 11.0(1595.4) | 13.2(50) | 17.7(5.4) | 54.4(16.6) | |||
| Item | HWD12000 |
| Overall dimensions | 23.66″×6.89″×6.9″ |
| (L×W×H) | 601mm×175mm×176mm |
| Net weight (Ibs/kg) | 45.9 kg |
| EAN | 7439656989989 |
|---|---|
| Weight | 42.000000 |
| HS Code | 842531-00-90 |
| Energy source | Hydraulic |
| Speed (m/min) | 20+ |
