RUNVA 2S EWD 5500 (kg) 12V + high-quality radio remote control

The RUNVA 2S EWD 5500 impresses with 12000 lbs of pulling power and two speed options. The series-wound motor delivers 5.4 kW / 7.2 hp at 12V, while the reduced gearbox delivers impressive performance with ratios of 267:1 (slow) and 86:1 (fast). The Ø13/32″×83.7′ (ø10.2mm×25.5m) steel cable and robust construction make it ideal for a wide range of applications. The high-quality radio remote control allows for precise operation.

Technical Specifications:

• Traction force: 5443 kg
• Motor: Series wound, 12V Input: 5.4kW / 7.2hp; Output: 2.4kW / 3.2hp
• Gear ratio: 267:1 (slow); 86:1 (fast)
• Steel cable: Ø13/32″×83.7′ (ø10.2mm×25.5m)
• Drum size: Ø2.48″×8.8″ (ø63mm×223mm)
• Mounting pattern: 10″×4.5″ (254mm×114.3mm) 4-M10

Operating speeds: Slow:

• 0 lbs: 29.5 ft/min (9.0 m/min) - 70 A
• 6000 lbs: 2.4 m/min (7.9 ft/min) - 250 A
• 9000 lbs: 2.0 m/min (6.6 ft/min) - 345 A
• 12000 lbs: 4.9 ft/min (1.5 m/min) - 450 A

Fast:

• 0 lbs: 27.0 m/min (88.6 ft/min) - 75 A
• 3000 lbs: 6.8 m/min (22.3 ft/min) - 290 A
• 4000 lbs: 4.2 m/min (13.8 ft/min) - 400 A
• 5000 lbs: 3.2 m/min (10.5 ft/min) - 490 A

Additional details:

• Dimensions: 637 × 160 × 254 mm (25.1×6.3×10.0″)
• Weight: 41 kg
• Drive: Direct current
• Voltage: 12V
• Speed: 24 m/min
• Traction force: 4536kg
• Cable length: 25 m
• Cable diameter: 9.2 mm

Warning: Read the safety instructions before use.

Warranty: An extended warranty protects your investment.
