SR 2041 (kg) E 12V powerful winch with high-quality radio remote control and Synthetic rope

The SR 2041 (kg) E 12V powerful winch is equipped with a high-quality radio remote control for easy operation. The Synthetic rope offers high tensile strength and is durable. The winch has a 12V permanent magnet motor and an impressive pulling force of 2041 kg.

Technical Specifications (EWX4500):

• Rated pulling force: 2041 kg
• Motor: Permanent magnet
  • 12V: Input: 2.4 kW / 3.2 hp; Power: 1.0 kW / 1.3 hp
  • 24V: Input: 2.9 kW / 3.9 hp; Output: 1.3 kW / 1.7 hp
• Gear ratio: 172:1
• Rope (Ø×L): Ø15/64"×47.6' (Ø 6.0 mm×14.5 m)
• Drum size (Ø×L): Ø1.77"×3.8" (Ø 45 mm×93 mm)
• Mounting hole pattern: 5.1"×3.78" (129 mm×96 mm) 4-M8
• Item number: 3.E.1
• Overall dimensions (L×W×H): 14.9"×5.0"×6.5" (378 mm ×126 mm ×165 mm)
• Net weight: 13.0 kg

Traction force, speed, amps, volts (first position):

• 0 Ibs: 3.6 m/min (11.6 ft/min) - 12V DC: 20 A, 24V DC: 15 A
• 1500 Ibs: 2.8 m/min (9.2 ft/min) - 12V DC: 70 A, 24V DC: 40 A
• 2500 Ibs: 7.8 ft/min (2.4 m/min) - 12V DC: 100 A, 24V DC: 65 A
• 3500 Ibs: 6.6 ft/min (2.0 m/min) - 12V DC: 140 A, 24V DC: 80 A
• 4500 Ibs: 4.9 ft/min (1.5 m/min) - 12V DC: 200 A, 24V DC: 130 A

Cable length and capacity per layer:

• Layer 1: 2041 kg (4500 Ibs) - 2.3 m (7.6 ft)
• Layer 2: 1652 kg - 5.2 m (17.0 ft)
• Layer 3: 1388 kg - 8.3 m (20 ft)
• Layer 4: 1196 kg - 11.8 m (17.0 ft)
• Position 5: 2254 Ibs (1023 kg) - 47.6 ft (14.5 m)

Winch dimensions (EWX4500U):

• Own weight: 10 kg
• Drive: DC
• Voltage: 12V
• Speed: 3 m/min
• Traction force: 2041 kg
• Rope length: 14 m
• Rope diameter: 6 mm

Warranty: Information about the warranty can be found in the warranty conditions.
