Chain hoist 5,000 kg 400 V -10 m-2 speeds-radio remote control with 2 transmitters + cable control

Chain hoist 5,000 kg 400 V - 2 speeds-radio remote control with 2 transmitters-cable operation

Hoist HHER05-02FS 400V/50 hz 10 mtr

• • • SPECIFICATION
      • Capacity: 5 ton
      • Lifting Speed: 0.4~2.7 m/min - Inverter stepless
      • Lifting motor: 3.0 kW
      • Input Voltage: 230v/50hz/1p

• ELECTRIC HOIST DATA

• • General:

  Type ...........................................................	Chain Type with Motorized Trolley
  Model ..........................................................	HHBB05-02FS
  Capacity .......................................................	5 ton
  Test load ......................................................	6.25 ton
  HS Code ......................................................	8425110000
  Noise level ....................................................	81 db

  • Operating environment

  Hoist use ......................................................	Indoor
  Operating temperature range ............................	-20℃ ~ +40℃
  Operating humidity range .................................	≤80%

  • Lifting Mechanism

  Hoist lifting speed ...........................................	0.4~2.7 m/min - Inverter stepless
  Motor power ..................................................	3.0 kW
  Rotation Speed ..............................................	1440 r/min
  Hoist group ....................................................	ISO/FEM 2m/M5
  Protection class .............................................	IP 66
  Load chain falls number....................................	2 fall
  Load chain size ..............................................	11.2 mm

  • ELECTRICAL

  Input Voltage .................................................	230v/50hz/1p
  Control Voltage ..............................................	24v

• Connection 400 V

It may appear that the hoist does not work. With the 3 phases of 400 V, the hoist is protected against running in the wrong direction, so up arrow would work in the wrong direction and the chain would go down. That is why the hoist does not seem to work. Reverse 2 phases and then the hoist will work. The radio control receiver will then also start to greet you with LED lights illuminating.

• Switching on the radio control transmitters

To turn on the transmitter, pull out the emergency stop and then press the two green buttons simultaneously. You will hear a sound and the receiver will indicate with the large red light that you can hoist and drive back and forth. This for you as information that you are connected and for everyone else as an additional warning not to stay near the hoist.

You have two transmitters. They can only work in turn, never simultaneously. However, the last one enabled by the two green buttons pushes the other one away. Until the other via the two green buttons again in simultaneous pressing would take over again.
