Goldwinch HWV 6804 (kg) High-end hydraulic winch
€1,730.30 €1,430.00
Discover the power of the Goldwinch HWV 6804 (kg) hydraulic winch - the ultimate combination of air and manual coupler for professional applications. Includes balance valve, cable rope and pressure roller cable tensioner for maximum versatility.
SKU
5.H.3
EAN Number:
7439657025068
Certification Mark
Warum winch-shop.eu?
- All items in stock – shipped directly from our own warehouse
- Directly from the manufacturer
- Fast delivery (1-3 days)
- Own service workshop
The Goldwinch HWV 6804 (kg) hydraulic winch sets high-end standards. The combination of air and hand clutch allows flexible operation. The professional hydraulic drive ensures reliable performance in any situation.
Technical specifications:
- Nominal compression force: 6804 kg
- Displacement motor: 160 ml/r
- Oil flow: 5~60 L/min
- Pressure: 16 MPa
- Gear ratio: 17.3:1
- Rope (diam.×L): Ø12mm×26.5m
- Drum size (diam.×L): Ø127mm×266mm
- Mounting pattern: 303.5mm×114.3mm or 368.5mm×171.2mm 4-M12
Performance in different situations:
-
First layer:
- Pulling force: 6804kg
- Speed: 1.3 m/min
-
Second layer:
- Pulling force: 5807kg
- Speed: 2.6 m/min
-
Third layer:
- Traction force: 5062 kg
- Speed: 3.8 m/min
Dimensions and weight:
- Dimensions (L×W×H): 735 mm × 300 mm × 277 mm
- Net weight: 83.6 kg
The Goldwinch HWV 6804 (kg) is the ideal choice for demanding applications, offering maximum performance and reliability. Order now and experience the power of hydraulics!
| Rated traction force | 6804 kg |
| Displacement motor | 160 ml/r |
| Oil flow | 5~60L/min |
| Pressure | 16Mpa |
| Gear reduction ratio | 17.3:1 |
| Cable(Dia.×L) | Ø12mm×26.5m |
| Drum Size (Dia.× L) | Ø127mm×266mm |
| Mounting Bolt Pattern | 303.5mm×114.3mm or 368.5mm×171.2mm 4-M12 |
| Line Speed Ampere Volts First layer | Line pull force and cable capacity in layer Line pull force | |||||
| Line pull force Lbs.(kg) | Pressure Bar | Flow L/min | Line speed m/min | Low cable | Rated tensile force kg | Total cable on drum (m) |
| 0 | 20 | 10 | 1.3 | 1 | 6804 | 9.0 |
| 8000(3629) | 92 | 20 | 2.6 | 2 | 5807 | 20.0 |
| 10000(4536) | 115 | 30 | 3.8 | 3 | 5062 | 26.5 |
| 12000(5448) | 140 | 40 | 5.1 | |||
| 15000(6810) | 175 | 50 | 6.4 | |||
| Item | HWV15000 |
| Overall dimensions | |
| (L×W×H) | 735 mm ×300 mm ×277 mm |
| Net weight (Ibs/kg) | 83.6 kg |
| EAN | 7439657025068 |
|---|---|
| Weight | 103.000000 |
| HS Code | 842531-00-90 |
| Applications | Cars and vehicles, Industry and workshops, Rescue services and assistance, Shipbuilding and ports |
| Type of winch or parts | Pull winch: Cut load stands still or slides |
| Energy source | Hydraulic |
| Force | 5001-8000 |
| Speed (m/min) | 6-10 |
| Cable length (m) | 21-30 |
